6000 Series Grade 1 Exit Devices
14
6160(F) Concealed Vertical Rod
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Item Part No. Description
1
Latch Case Assembly
60-6020-0360-048 LH
60-6020-0365-048 RH
6160, 6160F
2
Cover, Latch Assembly
60-6000-X004-FIN 6160
Not Available
6160F
35 60-7020-0055-048 Bottom Bolt Case, 6160F
36 60-7220-1019-059 Top Rod
37
Rod Extension Assembly
60-1510-0282-000 12" Rod Assembly
60-1510-0281-000 24" Rod Assembly
46
81-9500-1581-000 CVR Pack
Consists of the following:
60-7010-1070-018 Floor Bolt
60-7010-1055-200 Strike
81-9500-1696-000 761 Top Strike Packet
60-7120-1047-048 Pin, Rod Yoke (2)
60-7140-1026-059 Set Screw, Yoke Pin (2)
60-7020-1064-059 Yoke Pin Shim (2)
60-7000-0217-059 Spindle Assy, 2 to 2-1/2 Door
99-9958-0045-999 Cotter Pin (5)
99-9999-4526-999 Ring, Retaining (2)
81-9500-1580-058 Screw Pack
81-0014-0430-036 2" Temp Screw (2)
47 60-7160-0060-000 Top Latch & Bracket Assembly, 6160(F)
49 60-7020-0059-000 Bottom Rod & Coupler Assembly
51 60-7220-7025-000 Top Rod Tube
52 60-7220-0030-999 Arm & Bracket Assy. (2)
