Yale
®
Commercial Solutions
41
480F, 481F, 482F, 483F Trim
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
*See page 56 for cylinder collar applications.
Item Part No. Description
1 60-7200-X371 Escutcheon 7.25" (Pull)
2 60-7200-X372 Escutcheon 7.25" (Nightlatch)
3 60-7200-X373 Escutcheon 9.00" (Pull)
4 60-7200-X376 Escutcheon 9.00" (Nightlatch)
5 60-7200-X374 Escutcheon 15.00" (Pull)
6 60-7200-X377 Escutcheon 15.00" (Nightlatch)
7 60-7200-X375 Escutcheon 18.00" (Pull)
8 60-7200-X378 Escutcheon 18.00" (Nightlatch)
9 60-7000-X431 Pull Tube 6.73"
10 60-7000-X432 Pull Tube 8.48"
11 60-7000-X433 Pull Tube 14.48"
12 60-7000-X434 Pull Tube 17.48"
13 60-7000-2428 Bracket
14 60-7000-2429 Bracket
15 99-9999-4905 Drive Screw Rivet (2)
16 60-7000-1039 Trim Post (2)
17 99-9999-4526 Retaining Ring (2)
18 99-9999-7156 Finish Washer (2)
19 81-0013-0670 1/4-20 x 1" Oval Head Screw (2)
