Assa Abloy Yale 656F User Manual

Yale
®
Commercial Solutions
21
Touchbar
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
*Covers which bare the UL Listing mark for Fire-Rating cannot be shipped with that marking. Therefore, covers for Fire-Rated Latch Case
Assemblies are not available.
Item Part No. Description
7
Cover, End
60-6000-4015-FIN 24" std
60-6000-4022-FIN 24' Cylinder Dogging
60-6000-4016-FIN 36" std
60-6000-4023-FIN 36" Cylinder Dogging
60-6000-4017-FIN 42" std
60-6000-4024-FIN 42" Cylinder Dogging
60-6000-4018-FIN 48" std
60-6000-4025-FIN 48" Cylinder Dogging
8 60-6000-6002-200 Touch Pad Cap, Front
9 60-6000-6001-200 Touch Pad Cap, Rear
10 60-6000-9001-999 Bar Cap, Black Nylon
11 60-6000-6003-XXX End Cap
12
60-6000-9008-999 Trim Slide (All except Mortise)
60-6000-1059-048 Trim Slide (Mortise)
14
Dogging Assembly
60-6000-0010-999 Standard Hex Key Dog.
60-6000-0011-999 Cylinder, Dogging
15 60-7000-1131-036 Dogging Key (5/32" hex)
16 99-9999-4123-999 Dogging Hole Plug
17 60-7000-2421-000 Cylinder Nut
18 60-2000-9153-999 Cylinder Spacer Sleeve
19
Collar, Dogging Cylinder
None Required
1-1/8" Cylinder
60-6765-X001-FIN 1-1/4" Cylinder
60-6765-X002-FIN 1-3/8" Cylinder
60-6765-X013-FIN 1-1/2" Cylinder
60-6765-X018-FIN 1-11/16" Cylinder
20 As Ordered Dogging Cylinder (Mortise)
21
End Clamp Packet
81-9500-6000-999 RIM, CVR, SVR
81-9500-6001-999 RIM, CVR, SVR (F)
81-9500-6002-999 6150
81-9500-6003-999 6150(F)
Item Part No. Description
1
Latch Case Assembly
(Reversible) Specify Hand
60-6000-0419-048 6100
60-6000-0425-048 6100F
60-6200-0354-048 6200
60-6150-0005-048 6150, 6150F
60-6250-0001-048 6250
60-6010-0360-048 6170(F)
60-6210-0354-048 6210
60-6020-0360-048 6160(F)
60-6220-0354-048 6220
60-6030-0382-048 6130(F) (Includes Trim Slide)
2
*Cover, Latch Assembly
60-6000-X024-FIN 6100
60-6000-X023-FIN 6200
60-6000-X034-FIN 6150
60-6000-X033-FIN 6250
60-6000-X014-FIN 6170
60-6000-X013-FIN 6210
60-6000-X004-FIN 6160, 6130
60-6000-X003-FIN 6220
5
Bar & Carrier Assembly
60-6000-0024-FIN 24"
60-6000-0002-FIN 36"
60-6200-0019-FIN 36" Narrow
60-6000-0020-FIN 42"
60-6200-0021-FIN 42" Narrow
60-6000-0022-FIN 48"
60-6200-0023-FIN 48" Narrow
6
Cover, Bar
60-6000-X007-FIN 24"
60-6000-X001-FIN 36"
60-6000-X005-FIN 42"
60-6000-X006-FIN 48"
