Yale
®
Commercial Solutions
25
627F Trim
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
*See page 56 for cylinder collar applications.
Item Part No. Description
1 60-7000-0705-FIN Escutcheon Assembly
2
See Charts pages 54-55
Lever
3 See Chart page 56 Cylinder, Rim*
5 60-2000-6206-082 Housing, Cylinder
6 60-7000-1235-048 Screw, Cylinder Mounting (2)
11 60-7000-1328-048 Gear, Drive
12 60-7000-6220-999 Universal Spring Hub, Lever
14 99-9958-0047-999 Cotter Pin
15 99-9999-3516-999 Nut, Spindle
16
60-7000-9001-999 Thimble Insert, Nylon
(Levers) Not Shown
17
81-9500-1476-FIN Screw Packet, Mtg.
Consists of the following:
81-0013-0670-FIN Screw, 1/4-20 x 1 OPHMS (2)
99-9999-7156-FIN Washer, #14 Finish (2)
18
Spring, Grip Return
60-7000-1220-999 Levers, Universal Spring
To Next Page
