6000 Series Grade 1 Exit Devices
6
6210 Surface Vertical Rod
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Item Part No. Description
1
60-6210-0354-048 LH
60-6210-0364-048 RH
Latch Assembly
6210
2 60-6000-X013-FIN
Cover
6210
3 03-0080-5047-FIN
Sex Nut Pack (4)
(Fire Rated Only)
23 81-9500-1549-FIN
Screw Packet, Cover
#8-32 x 5/16”
UFPHMS (5)
32 60-7010-X040-FIN
Cover, Top & Bottom
Latches (2)
33
60-7010-0049-999
Top Latch
6210
Item Part No. Description
34
81-9500-1512-000 SVR Pack
Consists of the following:
60-7010-1038-048 Top Mtg. Plate
60-7010-1039-048 Bottom Mtg. Plate
60-7010-1067-048 Top Rod Connector
99-9999-4308-999 Rod Connecting Pin (2)
60-7000-1150-999 Drill Jig
60-7010-1070-018 Floor Bolt
60-7010-1055-200 Strike
81-9500-1546-000 Latch Mounting Screw Packet
81-9500-1454-200 791 Top Strike Packet
35
60-7010-0054-000
Bottom Bolt Case
6210
36 60-7010-X052-FIN Top Rod
37 60-7010-0020-FIN Bottom Rod Assembly
39
81-9500-1514-FIN Rod Guide Packet
Consists of the following:
60-7010-9050-999 Guide, Rod (1)
60-7010-X051-FIN Cover, Rod Guide (1)
81-3110-0412-058 Screw, #8 x 1/2 RHPSM (2)
81-3115-0308-FIN Screw, Rod Guide Cover
81-0011-0404-FIN Screw, #8-32 x 1/4 FPHMS (2)
40 81-9500-1464-200 Blade Stop Block Packet
