Yale
®
Commercial Solutions
37
426F, 428F, 429F Trim
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
*See page 56 for cylinder collar applications.
Item Part No. Description
1
Escutcheon Assembly
60-7000-0416-FIN 426F
60-7000-0417-FIN 428F, 429F
2
See Charts pages 54-55
Lever Assy.
3
See Chart page 56
Cylinder, Rim or Mortise*
5 60-7000-0215-000 Housing cylinder
6 60-7000-1235-048 Screw, Cylinder Mounting (2)
7 81-0016-2200-999 Screw, NL
8 60-7000-9002-999 Driver Gear Assembly
9 81-4414-0308-036 Screw, Tailpiece Plate, #6 x 3/8”, PHT-T-PH (2)
10
Tailpiece Assembly
60-7000-0610-059 1-3/4" Door Without Shim Kit
60-7000-0217-059 2" - 2-1/4" Door or Std. Door with Shim Kit
11 60-7000-1328-048 Gear, Drive
12 60-7000-6220-999 Universal Spring Hub, Lever
14 99-9958-0047-999 Cotter Pin
15 99-9999-3516-999 Nut, Spindle
16 60-7000-9001-999 Thimble Insert, Nylon (Levers) (Not Shown)
17
81-9500-1476-FIN Screw Packet, Mtg.
Consists of the following:
81-0013-0670-FIN Screw, 1/4-20 x 1 OPHMS (2)
99-9999-7156-FIN Washer, #14 Finish (2)
18
Spring, Grip Return
60-7000-1220-999 Levers, Universal Spring
19 60-7000-1306-999 Spring Under Tailpiece (Not Shown)
21 60-7000-1236-059 Washer Under Tailpiece (2) (Not Shown)
22 60-7000-1237-999 WASHER GEAR
23 60-7000-1305-059 Bushing (Not Shown)
24 60-7000-X055-FIN Front Bearing (Not Shown)
To Next Page
