6000 Series Grade 1 Exit Devices
30
633F, 635F Trim
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
* See page 56 for cylinder collar applications.
Item Part No. Description
1
Escutcheon Assembly
60-7000-0715-FIN 633F
60-7000-0714-FIN 635F
2 60-7000-X192-FIN Thumbpiece
3
See Chart Page 56
Cylinder, Rim*
5 60-7000-0215-000 Housing & Cam Assembly
6 60-7000-1235-048 Screw, Cylinder Mounting (2)
7 81-0016-2200-999 Screw, NL Function
9 81-4414-0308-036 Screw, Tailpiece Plate, #6 x 3/8 PHT-T-PH (2)
10 60-7000-0611-059 Tailpiece Assembly
17
81-9500-1476-FIN Screw Packet, Mtg.
Consists of the following:
81-0013-0670-FIN Screw, 1/4-20 x 1OPHMS (3)
99-9999-7156-FIN Washer, #14 Finish (3)
19 60-7000-1306-999 Spring Under Tailpiece
20 60-7000-1305-059 Hex Nut/Bushing for Spring
38 60-0010-2639-FIN Pull, Straight
39 60-7000-1039-048 Screw Post
40 99-9999-7154-036 Lock Washer, Screw Post
41 99-9999-5697-999 Spring, Thumbpiece (2)
42 60-7000-1190-059 Slider, Thumbpiece
43 60-7000-0214-000 Housing, Tailpiece Assy.
48 60-7000-1045-059 Pin, Thumbpiece
49 60-7000-1189-059 Thumbpiece Support Bracket
To Next Page
