Yale
®
Commercial Solutions
27
656F, 658F Trim
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
* See page 56 for cylinder collar applications.
Item Part No. Description
1
Escutcheon Assembly
60-7000-0703-FIN Cylinder x Lever (656F)
60-7000-0702-FIN Blank x Lever (658F)
2
See Charts pages 54-55
Lever
3
See Chart Page 56
Cylinder, Mortise*
14 99-9958-0047-999 Cotter Pin
15 99-9999-3518-999 Nut, Spindle
16 60-7000-9001-999
Thimble Insert, Nylon
(Levers) Not Shown
17
81-9500-1476-FIN Screw Packet, Mtg.
Consists of the following:
81-0013-0670-FIN Screw, 1/4-20 x 1 OPHMS (2)
99-9999-7156-FIN Washer, #14 Finish (2)
23 60-9958-0047-999 Washer, Spindle
24 60-7000-1328-048 Gear
25
Spindle
60-7030-1045-048 1-3/4" - 2-1/4"
60-7030-1026-048 2-1/4" - 3"
To Next Page
