6000 Series Grade 1 Exit Devices
22
Touchbar
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
6200
6100(F)
23
Item Part No. Description
22 81-3510-4750-999
Screw, Touch Bar Caps, Torx
Cap #6-32 x 3/4 (4)
23 81-9500-1545-FIN Screw Packet, Cover
24 81-3571-0418-999
Screw, Dogging Assy., #8-x 7/8
PH FL Self Tap (2)
25 60-6000-1036-048 Trim Slide Retainer
26 81-3571-0412-999
Screw, Latch Head to Carrier,
#8-18 x 1/2 PH FL Self Tap (2)
28 03-0080-5047-FIN
Sex Nut Packet (4)
Fire-rated Devices incl.
54 99-9999-4941-FIN Pop Rivet, 3/16"
To Next Page
