Assa Abloy Yale 656F User Manual

Yale
®
Commercial Solutions
23
626F, 628F, 629F Trim
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
*See page 56 for cylinder collar applications.
Item Part No. Description
12 60-7000-6220-999 Universal Spring Hub, Lever
14 99-9958-0047-999 Cotter Pin
15 99-9999-3516-999 Nut, Spindle
16 60-7000-9001-999
Thimble Insert, Nylon
(Levers) Not Shown
17
81-9500-1476-FIN Screw Packet, Mtg.
Consists of the following:
81-0013-0670-FIN Screw, 1/4-20 x 1 OPHMS (2)
99-9999-7156-FIN Washer, #14 Finish (2)
18
Spring, Grip Return
60-7000-1220-999 Levers, Universal Spring
19 60-7000-1306-999
Spring Not Shown Under
Tailpiece
20 60-7000-1365-999
Hex Nut / Bushing for
Spring Not Shown
21 60-7000-1236-059
Washer Under
Tailpiece (2) Not Shown
Item Part No. Description
1
Escutcheon Assembly
60-7000-0612-FIN 626F
60-7000-0615-FIN 628F, 629F
2
See Charts pages
54-55
Lever Assembly.
3 See Chart page 56 Cylinder, Rim*
5 60-7000-0215-000 Housing & Cam Assy.
6 60-7000-1235-048
Screw, Cylinder
Mounting (2)
7 81-0016-2200-999 Screw, NL
8 60-7000-9002-999 Driver Gear Assembly
9 81-4414-0308-036
Screw, Tailpiece Plate, #6 x 3/8",
PHT-T-PH (2)
10
Tailpiece Assembly
60-7000-0611-059
1-3/4" Door
Without Shim Kit
60-7000-0213-059
2" - 2-1/4" Door or Std. Door with
Shim Kit
11
Gear, Drive
60-7000-1328-048 Lever (626F, 628F)
60-7000-1011-059 Rigid Lever (629F)
