3. SPECIFICATIONS AND CONTROLS
3.1. SC6540 Functional Specifications
SC6540 MAIN
SC6540
SECONDARY
Input
115 VAC (+/-10%), 50/60 Hz, Single
Phase
230 VAC (+/-10%), 50/60 Hz Single
Phase
User Selectable
NA
Fuse
250V/2A/Fast-Blow
NA
PC Control
GPIB, USB/RS232, or Ethernet
NA
Scanner Control
1 Scanner Bus Output
Controls up to 4 additional Secondarys
1 Output and 1 Input
Maximum High
Voltage rating
5kV AC & DC
Maximum
Current rating
40 amperes
Number of
possible
channels
8 or 16*
HV output
Terminations
100 ft. reel HV cable rated for up to 30 kV with 8 HV connectors
GND output
Terminations
20 terminals provided, to accept 10/12 AWG hookup wire
(user supplied wire)
Temperature
32° - 104° F (0° - 40° C)
Humidity
0 – 80%
Altitude
6560ft (2000m)
Safety Agency
Listing
CE, cTUVus, RoHS2
Dimensions
2U with tilt-up front feet
17 x 4.07 x 12.96 in. W x H x D
(432 x 103 x 329 mm)
