NOTE: The Omnia I (8100) series is discontinued and replaced by Omnia
II (8200) series.
4.3.1. Cables and Connections Description
A number of hardware and interconnect cables are included with the SC6540
Scanner depending on its configuration and the number of modules. The following
hardware and interconnect cables are included with each of the following items:
DESCRIPTION
AR PART NUMBER
SC6540 SECONDARY AND OMNIA 8200
INTERCONNECT CABLES
1 – 25-Pin Scanner Bus Cable
38592
1 – High Voltage Cable
HS-8-12
1 – Ground Bond Output Cable
38555
1 – Ground Bond Return Cable
38556
2 – Probe HI/LO to Current/Return Cables
38879
1
SC6540 MAIN AND OMNIA 8200 INTERCONNECT
CABLES
1 – High Voltage Cable
HS-8-12
1 – Ground Bond Output Cable
38555
1 – Ground Bond Return Cable
38556
2 – Probe HI/LO to Current/Return Cables
38879
1
SC6540 SECONDARY AND OMNIA 8100
INTERCONNECT CABLES
1 – 25-Pin Scanner Bus Cable
38592
1 – High Voltage Cable
HS-8-12
1 – Ground Bond Output Cable
38555
1 – Ground Bond Return Cable
38556
SC6540 MAIN AND OMNIA 8100 INTERCONNECT
CABLES
1 – High Voltage Cable
HS-8-12
1 – Ground Bond Output Cable
38555
1 – Ground Bond Return Cable
38556
SC6540 HIGH VOLTAGE MODULE
8 – High Voltage Connectors and Assembly Instructions
HS-8-13
1 – 100 ft. (48.75 m) Reel of High Voltage Cable
37534
SC6540 GROUND BOND MODULE
20 – Hook-style Crimp Lugs
38599
1
Included with Omnia 8206, 8256, 8207 and 8257 only.
