6. REPLACEMENT PARTS
LISTERROR! BOOKMARK
NOT DEFINED.
Rev: D 9/14/2015 ECO 5783
Part Number
Qty.
Reference
Designator
Description
37478
1
-
High Voltage Connector
38794
2
-
2U Rack Mount Handle
38793
2
-
2U Rack Mount Bracket
37571
1
-
Earth Connector
38101
1
-
Feet Kit w/o Rubber Inserts
38102
4
-
Rubber Inserts
38846
1
IC 23
IC Microcontroller (SM89516AC)
38445
1
-
60A Binding Post (Black)
38446
1
-
60A Binding Post (Red)
38580
1
-
High Voltage Module
38581
1
-
Ground Bond Module
38583
1
CON6540
PCB Main Control Board
38584
1
DSP6540
PCB Display Board
38596
1
CSU6540
PCB High Voltage Board
38598
1
GB6540
PCB Ground Bond Board
SC6540 Main with GPIB and USB/RS-232 Only
38582
1
-
Power Module
38601
1
MAS6540
PCB Main/Power Board
SC6540 Main with Card Option Only
39063
1
USB/RS-232
USB/RS232 Interface Card
38305
1
-
GPIB Interface Card
38819
1
-
Ethernet Card
39051
1
-
Main Module with Card
39052
1
MAS6540
PCB Main/Power Board with Card
SC6540 Both Main Modules
33189
1
-
Line Cord (USA)
38069
1
-
Power Switch
37781
1
-
Fuse Holder (20mm)
38603
1
-
Fuse (2A/20mm/Fast-Blow)
Interconnect Accessories
37534
100ft
-
Wire Stranded 18 AWG WHT
30KVDC 100ft.
37884
1
-
High Voltage Splitter
38555
1
-
High Current Output Cable
(OMNIA 8100 Series)
38556
1
-
High Current Return Cable
(OMNIA 8100 Series)
38592
1
-
Scanner Bus Cable
