Associated Research SC6540 User Manual

43
HV
Example 3: A test system requiring 40 HV and 40 HC points set up in a different
configuration.
The main Scanner and the first secondary Scanner are set up with high voltage
modules in modules A and B. The second secondary Scanner is set up with one
high voltage module and one high current module. The remaining secondary
Scanners are set up with all high current modules.
SCANNER
TYPE
POSITION
CIRCUIT ADDRESS
CHANNELS
Main HV
A
Automatically assigned 0
1-8
Main HV
B
Automatically assigned 1
9-16
Secondary 1
HV
A
2
17-24
Secondary 1
HV
B
3
25-32
Secondary 2
HV
A
4
33-40
Secondary 2
HC
B
0
1-8
Secondary 3
HC
A
1
9-16
Secondary 3
HC
B
2
17-24
Secondary 4
HC
A
3
25-32
Secondary 4
HC
B
4
33-40
