TECHNICIANS' manual
63 of 108
13.5 SAE-DISPLAY version
The table below shows, for each model of machine, the code
for the control unit and the reference to the page with the
wiring diagram.
Machine
Control unit
power supply
Control unit
code
Giemme
Paragraph
Gicar
Paragraph
ARGENTA
JUN
120 V 18366 13.5.1
230 V 18365 13.5.1
1-2-3GR
120 V 18078 13.5.4
230 V 18079 13.5.4
4GR 230 V 18077 13.5.4
BRAVA
1-2-3GR
120 V 18090017 13.5.5 13.5.6
230 V 18090016 13.5.5 13.5.6
4GR 230 V 18090028 13.5.5 13.5.6
CALYPSO 1-2-3GR
120 V 18090030 13.5.7 13.5.8
230-240 V 18090031 13.5.7 13.5.8
230-240 V 18090031A 13.5.9 13.5.10
CALYPSO
DISPLAY
1-2-3-
4GR
120 V 18090079 13.5.13
230 V 18090080 13.5.13
230 V 18090080A 13.5.14
CKXE
CKX
120-230 V
18090067 13.5.16
CKXE 18090068 13.5.16
DENISE
1-2-3GR
120 V 18078 13.5.4
230 V 18079 13.5.4
4GR 230 V 18077 13.5.4
DIVINA
JUN
120 V 18371011 13.5.2
230 V 18371010 13.5.2
1-2-3GR
120 V 18090017 13.5.5 13.5.6
230-240 V 18090016 13.5.5 13.5.6
4GR
120 V 18090029 13.5.5 13.5.6
230-240 V 18090028 13.5.5 13.5.6
DORA
JUN
120 V 18366 13.5.1
230 V 18365 13.5.1
1-2-3GR
120 V 18090030 13.5.7 13.5.8
230-240 V 18090031 13.5.7 13.5.8
230-240 V 18090031A 13.5.9 13.5.10
FORMA
1-2GR
230 V
18088004 13.5.19
3-4GR 18088005 13.5.19
GLORIA 1-2-3GR
120 V 18090047 13.5.11 13.5.12
230 V 18090048 13.5.11 13.5.12
GLORIA
DISPLAY
1-2-3-
4GR
120 V 18090079 13.5.13
230 V 18090080 13.5.13
230 V 18090080A 13.5.14
GLORIA LCL 1-2-3GR
120 V 18090051 13.5.15
230 V 18090052 13.5.15
GLORIA R12 1-2-3GR
120 V 18090047 13.5.11 13.5.12
230 V 18090048 13.5.11 13.5.12
GLORIA R12
DISPLAY
1-2-3-
4GR
120 V 18090079 13.5.13
230 V 18090080 13.5.13
230 V 18090080A 13.5.14
LISA
JUN
120 V 18366 13.5.1
230 V 18365 13.5.1
1-2-3GR
120 V 18078 13.5.4
230 V 18079 13.5.4
4GR 230 V 18077 13.5.4
Machine
Control unit
power supply
Control unit
code
Giemme
Paragraph
Gicar
Paragraph
LISA R 1-2-3GR
120 V 18090047 13.5.11 13.5.12
230 V 18090048 13.5.11 13.5.12
LISA R
DISPLAY
1-2-3-
4GR
120 V 18090079 13.5.13
230 V 18090080 13.5.13
230 V 18090080A 13.5.14
LISA LCL 1-2-3GR
120 V 18090051 13.5.15
230 V 18090052 13.5.15
NEW START 1-2-3GR
120 V 18090030 13.5.7 13.5.8
230-240 V 18090031 13.5.7 13.5.8
230-240 V 18090031A 13.5.9 13.5.10
PERLA
JUN
120 V 18090065 15.3.3
230 V 18090066 15.3.3
1-2-3GR
120 V 18090047 13.5.11 13.5.12
230 V 18090048 13.5.11 13.5.12
PERLA
DISPLAY
1-2-3-
4GR
120 V 18090079 13.5.13
230 V 18090080 13.5.13
230 V 18090080A 13.5.14
PERLA LCL 1-2-3GR
120 V 18090051 13.5.15
230 V 18090052 13.5.15
PRATIC 1-2-3GR
120 V 18090030 13.5.7 13.5.8
230-240 V 18090031 13.5.7 13.5.8
230-240 V 18090031A 13.5.9 13.5.10
PRATIC
AVANT
1-2-3GR
120 V 18090030 13.5.7 13.5.8
230-240 V 18090031 13.5.7 13.5.8
230-240 V 18090031A 13.5.9 13.5.10
PRATIC
AVANT EXTRA
1-2-3GR
120 V 18090030 13.5.7 13.5.8
230-240 V 18090031 13.5.7 13.5.8
230-240 V 18090031A 13.5.9 13.5.10
SETTANTA 1-2-3GR
120 V 18090047 13.5.11 13.5.12
230 V 18090048 13.5.11 13.5.12
SETTANTA
DISPLAY
1-2-3-
4GR
120 V 18090079 13.5.13
230 V 18090080 13.5.13
230 V 18090080A 13.5.14
SETTANTA
LCL
1-2-3GR
120 V 18090051 13.5.15
230 V 18090052 13.5.15
SIBILLA 1-2-3GR
120 V 18090047 13.5.11 13.5.12
230 V 18090048 13.5.11 13.5.12
SIBILLA
DISPLAY
1-2-3-
4GR
120 V 18090079 13.5.13
230 V 18090080 13.5.13
230 V 18090080A 13.5.14
TANYA 1-2-3GR
120 V 18090030 13.5.7 13.5.8
230-240 V 18090031 13.5.7 13.5.8
230-240 V 18090031A 13.5.9 13.5.10
TANYA
CAPS-PODS
2GR
120 V 18090146 13.5.20
230 V 18090130 13.5.20
TOUCH
1-2GR
230 V
18088000 13.5.18
3-4GR 18088001 13.5.18
VANIA
JUN
120 V 18371011 13.5.2
230 V 18371010 13.5.2
1-2-3GR
120 V 18090017 13.5.5 13.5.6
230-240 V 18090016 13.5.5 13.5.6
