Astraada DRV-24 User Manual

Astraada DRV-24 frequency inverters Appendix B
116
B.2 Inverter chart
Wall mounting of 0.75~2.2kW inverters
Dimension (unit: mm)
Model
W1
W2
H1
H2
D1
D2
Installati
on hole
(d)
AS24DRV20C4
80.0
60.0
160.0
150.0
123.5
120.3
5
AS24DRV20C7
80.0
60.0
160.0
150.0
123.5
120.3
5
AS24DRV21C5
80.0
60.0
185.0
175.0
140.5
137.3
5
AS24DRV22C2
80.0
60.0
185.0
175.0
140.5
137.3
5
AS24DRV40C7
80.0
60.0
185.0
175.0
140.5
137.3
5
AS24DRV41C5
80.0
60.0
185.0
175.0
140.5
137.3
5
AS24DRV42C2
80.0
60.0
185.0
175.0
140.5
137.3
5
Rail mounting of inverters of 1PH 230V/3PH 40V (≤2.2kW)
Dimension (unit: mm)
Model
W1
H1
H3
H4
D1
D2
Installati
on hole
(d)
AS24DRV20C4
80.0
160.0
35.4
36.6
123.5
120.3
5
AS24DRV20C7
80.0
160.0
35.4
36.6
123.5
120.3
5
