Note: The installation bracket is optional.
Appendix C Peripheral Options and Parts
This chapter describes how to select the options and parts of Astraada DRV-24 series.
C.1 Peripheral wiring
Below is the peripheral wiring of Astraada DRV-24 series inverters.
Including the external keypads with
and without the function of parameter
copying.
When the external keypad with the
function of parameter copying is valid,
the local keypad is off; when the
external keypad without the function
of parameter copying is valid, the local
and external keypads are on at the
same time.
