Note:
The rated derate voltage of the input reactor is 2%±15%.The rated derate voltage of the output
reactor is 1%±15%. Above options are external, the customer should indicate when purchasing.
C.6 Filter
C.6.1 C3 Filter type instruction
AS20FL I 4 006
A B C D
AS20FL: inverter filter series
Filter type
I:power supply filter
U:output filter
Voltage degree
2：AC 1PH 220V(-15%)~240V(+10%)
4: AC 3PH 380V (-15%)~440V(+10%)
3-digit development serial number. For example, 003 stands for
the serial number of C3 filters in development
C.6.2 C3 filter
External C3 filers are optional for Astraada DRV-24 series inverters of 1PH 230V/3PH 400V (≤2.2kW).
The inverters of 3PH 400V (≥4kW) have the embedded C3 filers which can be selected to connect by
J10 (J10 is packed with the manual).
