Astraada DRV-24 User Manual

Astraada DRV-24 frequency inverters Function Parameters
26
corresponds to the third level menu.
1. Below is the instruction of the function lists:
The first column “Function code”:codes of function parameter group and parameters；
The second column “Name”:full name of function parameters；
The third column “Detailed illustration of parameters”:Detailed illustration of the function
parameters
The fourth column “Default value”:the original factory set value of the function parameter；
The fifth column “Modify”: the modifying character of function codes (the parameters can be
modified or not and the modifying conditions),below is the instruction:
“○”: means the set value of the parameter can be modified on stop and running state；
“◎”: means the set value of the parameter can not be modified on the running state；
“●”: means the value of the parameter is the real detection value which can not be modified.
Functio
n code
Name
Detailed instruction of parameters
Defaul
t value
Modify
P00 Group Basic function group
P00.00
Speed
control
mode
0: SVC 0
.No need to install encoders. Suitable in
applications which need low frequency, big
torque for high accuracy of rotating speed and
torque control. Relative to mode 1, it is more
suitable for the applications which need small
power.
1: SVC 1
1 is suitable in high performance cases with the
advantage of high accuracy of rotating speed
and torque. It does not need to install pulse
encoder.
2:SVPWM control
2 is suitable in applications which do not need
high control accuracy, such as the load of fan
and pump. One inverter can drive multiple
motors.
1
◎
P00.01
Run
command
channel
Select the run command channel of the
inverter.
The control command of the inverter includes:
start, stop, forward/reverse rotating, jogging
and fault reset.
0:Keypad running command channel
(“LOCAL/REMOT” light off)
Carry out the command control by RUN,
STOP/RST on the keypad.
Set the multi-function key QUICK/JOG to
FWD/REVC shifting function (P07.02=3) to
change the running direction; press RUN and
STOP/RST simultaneously in running state to
make the inverter coast to stop.
1:Terminal running command channel
(“LOCAL/REMOT” flickering)
Carry out the running command control by the
0
○
