Astraada DRV-24 frequency inverters Function Parameters
66
Functio
n code
Name
Detailed instruction of parameters
Defaul
t value
Modify
LED tens (for factory commissioning)
0: Light overcommission; in zone 1
1: Heavy overcommission; in zone 2
The default value of the inverters of 1PH
230V/3PH 400V (≤2.2kW) is 00;
The default value of the inverters of 3PH 380V
(≥4kW) is 01.
0x01
P08.42
Keypad data
control
setting
0x0000~0x1223
LED ones:frequency enable selection
0:Both ∧/∨ keys and analog potentiometer
adjustments are valid
1:Only ∧/∨ keys adjustment is valid
2:Only analog potentiometer adjustments is
valid
3:Neither ∧/∨ keys nor digital potentiometer
adjustments are valid
LED tens: frequency control selection
0:Only valid when P00.06=0 or P00.07=0
1:Valid for all frequency setting manner
2:Invalid for multi-step speed when multi-step
speed has the priority
LED hundreds: action selection during stopping
0:Setting is valid
1:Valid during running, cleared after stopping
2:Valid during running, cleared after receiving
the stop command
LED thousands: ∧/∨ keys and analog
potentiometer integral function
0:The Integral function is valid
1:The Integral function is invalid
0x0000
○
P08.43
Integral
ratio of the
keypad
potentiome
ter
0.01~10.00s
0.10s
○
P08.44
UP/DOWN
terminals
control
setting
0x00~0x221
LED ones: frequency control selection
0:UP/DOWN terminals setting valid
1:UP/DOWN terminals setting valid
LED tens: frequency control selection
0:Only valid when P00.06=0 or P00.07=0
1:All frequency means are valid
2:When the multi-step are priority, it is invalid
to the multi-step
LED hundreds: action selection when stop
0:Setting valid
1: Valid in the running, clear after stop
0x000
○
