Astraada DRV-24 User Manual

Astraada DRV-24 frequency inverters Function Parameters
68
Functio
n code
Name
Detailed instruction of parameters
Defaul
t value
Modify
motor stop, as well as to change the rotation
speed of the motor. Its other advantages are:
Brake immediately after the stop command. It
does not need to wait the magnetic flux
weaken.
The cooling is better. The current of the stator
other than the rotor increases during magnetic
flux braking, while the cooling of the stator is
more effective than the rotor.
P08.51
Input power
factor of
the inverter
This function code is used to adjust the
displayed current of the AC input side.
Setting range:0.00~1.00
0.56
○
P09 Group PID control
P09.00
PID
reference
source
When the frequency command selection
(P00.06, P00. 07) is 7 or the voltage setting
channel selection (P04.27) is 6, the running
mode of the inverter is procedure PID
controlled.
The parameter determines the target given
channel during the PID procures.
0:Keypad digital given(P09.01)
1:Analog channel AI1 given
2:Analog channel AI2 given
3:Analog channel AI3 set
4:High speed pulse HDI set
5:Multi-step speed set
6:MODBUS communication set
7~9:Reserved
The setting target of procedure PID is a relative
one, 100% of the setting equals to 100% of the
response of the controlled system.
The system is calculated according to the
relative value (0~100.0%).
Note: Multi-step speed given, it is realized by
setting P10 group parameters.
0
○
P09.01
Keypad PID
preset
When P09.00=0, set the parameter whose
basic value is the feedback value of the system.
The setting range:-100.0%~100.0%
0.0%
○
P09.02
PID
feedback
source
Select the PID channel by the parameter.
0:Analog channel AI1 feedback
1:Analog channel AI2 feedback
2:Analog channel AI3 feedback
3:High speed HDI feedback
4:MODBUS communication feedback
5~7:Reserved
Note: The reference channel and the feedback
channel can not coincide, otherwise, PID can
0
○
