S I G N A T U R E
18
• There is an arrow on the head of the ow detector. Make sure that this arrow is parallel to
the pipe shaft and pointing in the direction that the water ows.
FLOW
• Do not install the ow detector near magnetic objects. They could affect the operation of
the magnetic device it contains and reduce its reliability.
7.6.4. INSTALLATION OF THE PH/ORP SENSOR
Insert the pH and ORP sensors into their corresponding places of the holder.
Loosen the connection screws and insert the sensor into the holder.
The sensors must be installed in the holder so that it is guaranteed that the sensors lo-
cated in their ends are always submerged in the water circulating through the pipe.
Always install the sensors vertically or with a maximum inclination of 40º.
•
•
•
•
