PLG12863E AFI4700 Pilot’s Guide 25
Table 2-2: Flight Director Vertical Modes
Armed
Active
Description
ALT
Altitude capture mode
VS
Vertical speed climb or descend
IAS
Indicated air speed climb or descend
VGPS
VGPS
GPS navigation mode or GPS approach
mode (vertical guidance)
GS
GS
Glideslope capture mode
GA
Go around mode
Autopilot modes are annunciated along the top of the display. White
indicates armed modes and green indicates active modes. Armed or
captured modes are displayed in yellow on the display not coupled to
the flight director. The AFI4700 is designed to mirror the autopilot
panel. Refer to your particular autopilot manual for specific information
and operating instructions.
