PLG12863E AFI4700 Pilot’s Guide 61
Active Navigation Source
Displays the active navigation source, as selected by the NAV bezel
button. VOR Map mode is only available when VOR1 or VOR2 is the
active navigation source.
Station
A green navaid icon represents the station on a map.
TO Course Line
The solid green line extending from the station is the TO course line.
This line rotates around the station when the Course knob is rotated.
FROM Course Line
The dashed green line extending from the station is the FROM course
line. This line rotates around the station when the Course knob is
rotated.
3.3.5.1 Using the VOR Map
As the course knob rotates, the solid green TO course and dashed
green FROM course lines rotate around the station. To fly directly to
the station, line up the solid green line between the aircraft and the
navaid. To fly directly away from the station, line up the dashed green
line between the aircraft and the navaid.
An example of flying a heading to intercept the 20° radial is provided
both using the CDI and the VOR map.
