Astronautics RoadRunner AFI4700 - 6 Symbol Quick Reference; Map Symbols; Table 6-1: GPS Map Symbols

PLG12863E AFI4700 Pilot’s Guide 86
6 Symbol Quick Reference
Note: The following tables describe the symbols that are located on
the HSI Map displays.
6.1 Map Symbols
Table 6-1: GPS Map Symbols
Symbol
Description
Waypoint
VORTAC
TACAN
VOR
DME
VOR/DME (collocated)
Airport
NDB
Altitude Profile Point
Intersection
