Asus FA617N - Usb Board

USB BOARD
Step 1 : Disconnect the (yellow mark) connectors then remove USB BD FFC.
Step 2 : Remove the screw*1pc then remove USB BOARD.
Back
18
Disassembly Notice
1
Screws QTY Spec Torque (kgf-cm)
1 SCREW M2*3L (5.6,0.8) (K) #1 2.0
±
0.2
2
Remove
The device has an Ambient Light Sensor (ALS) for power-off protection Function.
