華碩 P8H61-M LX3 系列主板用戶手冊 1-13
1.7.2 內存設置
您可以任意選擇使用 1GB、2GB、4GB 與 8GB unbuffered non-ECC DDR3 內存
條至本主板的 DIMM 插槽上。
內存條默認頻率依SPD 而變化,這是從內存條讀寫數據的標準方法
在默認狀態下,一些超頻內存條會以低於供應商標示的頻率運作。若要
讓內存條以供應商的數值或更高的頻率運行,請參考“2.4 Ai Tweaker
菜單”一節中,手動調整內存頻率的說明。
在全負載(2 DIMM)或超頻設置下,請使用更有效的散熱系統以確保
系統穩定性。
您可以在通道 A 與通道 B 安裝不同容量的內存條,在雙通道設置中,
系統會偵測較低容量通道的內存容量。任何在較高容量通道的其他內存
容量,會被偵測為單通道模式運行。
在本主板請使用相同 CAS(CAS-Latency 行地址控制器延遲時間)值
內存條。建議您使用同一廠商所生產的相同容量型號的內存。
由於 Windows
®
32-bit 操作系統內存地址的限制,當您安裝 4GB 或更
大內存時,實際可使用的內存將為 3GB 或更小。為了更加有效地使用
內存空間,我們建議您做以下操作:
- 若您安裝 Windows
®
32-bit 操作系統,請安裝最多 3GB 總內存。
- 若您要安裝 4GB 或更多總內存,請安裝 Windows
®
64-bit 操作
系統。
•本主板不支持由 512Mb(64MB)或更小容量的芯片構成的內存條。
P8H61-M LX3 系列主板內存合格供應商列表(QVL)
DDR3-1066MHz
供應商 型號 容量
SS/DS
芯片廠商 芯片型號 時序 電壓
支持內存插槽
(可選)
A* B*
Crucial CT12864BA1067.8FF 1GB SS Micron 9GF22D9KPT 7 -
ELPIDA EBJ10UE8EDF0-AE-F 1GB SS ELPIDA J1108EDSE-DJ-F -
1.35V(low
voltage)
ELPIDA EBJ21UE8EDF0-AE-F 2GB DS ELPIDA J1108EDSE-DJ-F -
1.35V(low
voltage)
KINGSTON KVR1066D3N7/2G 2GB DS ELPIDA J1108BDSE-DJ-F 7 1.5V
KINGSTON KVR1066D3N7/4G 4GB DS Hynix H5TQ2G83AFR 7 1.5V
Micron MT16JTF25664AZ-1G1F1 2GB DS Micron 9HF22D9KPT 7 -
