第二章：BIOS 信息2-22
只有將【Chassis Fan Profile】項目設為 [Manual] 時，以下項目才會出
現。
Chassis Upper Temperature [70]
使用 <+> / <-> 鍵調整機箱溫度上限。設置值範圍從 40ºC 到 90ºC。
Chassis Fan Max. Duty Cycle(%) [100]
使用 <+> / <-> 鍵調整機箱風扇最大轉速。設置值範圍從 60% 到 100%。
當機箱溫度達到上限時，機箱風扇會以最大的轉速運行。
Chassis Lower Temperature [40]
顯示機箱溫度下限。
Chassis Fan Min. Duty Cycle(%) [60]
使用 <+> / <-> 鍵調整機箱風扇最小轉速。設置值範圍從 60% 到 100%。
當機箱溫度低於 40ºC 時，機箱風扇會以最小的轉速運行。
2.6.5 CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage
本系列主板具有電壓監控的功能，用來確保主板以及 CPU 接受正確的電壓準位，以
及穩定的電流供應。若您不想檢測此項目，請選擇 [Ignored]。
2.6.6 Anti Surge Support [Enabled]
本項目用來開啟或關閉電涌全保護功能。設置值有：[Disabled] [Enabled]

Asus P8H61-M LX3 PLUS Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1708S
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1748 MB
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	Gigabit Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	UEFI
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	173 mm
Width	226 mm
