Asus P8H61-M LX3 PLUS User Manual

第二章：BIOS 信息2-20
2.6 監控菜單（Monitor）
本菜單顯示系統溫度/電源狀態，並可用來變更風扇設置。
2.6.1 CPU Temperature / MB Temperature [xxxºC/xxxºF]
本主板具備了中央處理器 / 主板的溫度感測器，可自動檢測並顯示目前處理器的溫
度。若您不想顯示檢測到的溫度，請選擇 [Ignored]。
2.6.2 CPU / Chassis Fan Speed [xxxx RPM] 或 [Ignore] / [N/A]
主板具備中央處理器 / 電源風扇轉速 RPM（Rotations Per Minute）監控功能。
如果主板上沒有連接風扇，這裡會顯示 [N/A]。若您不想顯示檢測到的速度，請選擇
[Ignored]。
2.6.3 CPU Q-Fan Control [Enabled]
[Disabled] 關閉 CPU Q-Fan 控制功能。
[Enabled] 開啟 CPU Q-Fan 控制功能。
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
Version 2.00.1201. Copyright (C) 2011 American Megatrends, Inc.
CPU Temperature
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
EFI BIOS Utility - Advanced Mode
CPU Temperature +45ºC / +113ºF
MB Temperature +34ºC / +93ºF
CPU Fan Speed 4515 RPM
Chassis Fan Speed N/A
CPU Q-Fan Control Enabled
CPU Fan Speed Low Limit 600 RPM
CPU Fan Prole Standard
Chassis Q-Fan Control Enabled
Chassis Fan Speed Low Limit 600 RPM
Chassis Fan Prole Standard
CPU Voltage +1.184 V
3.3V Voltage +3.312 V
5V Voltage +5.080 V
12V Voltage +12.192 V
向下滾動以顯示以下項目：
Version 2.00.1201. Copyright (C) 2011 American Megatrends, Inc.
Anti Surge Support Enabled

Asus P8H61-M LX3 PLUS Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1708S
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1748 MB
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	Gigabit Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	UEFI
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	173 mm
Width	226 mm
