第二章：BIOS 信息2-6
升級 BIOS 文件
請依照以下步驟用 BIOS Updater 工具程序升級 BIOS 文件：
1. 在 FreeDOS 提示符後輸入
bupdater /pc /g 並按下 ＜Enter＞。
D:\>bupdater /pc /g
2. BIOS Updater 畫面出現，如下圖。
3. 按下 ＜Tab＞ 鍵在各設置欄之間切換，接著用 ＜Up/Down/Home/End＞ 鍵來
選擇 BIOS 文件並按下 ＜Enter＞。BIOS Updater 會檢查您所選擇的 BIOS 文件
並提示您確認是否要升級 BIOS。
Are you sure to update BIOS?
Yes No
4. 選擇 [Yes] 並按下 ＜Enter＞。當 BIOS 升級完畢後，按 ＜ESC＞ 退出 BIOS
Updater。重新啟動您的電腦。
當升級 BIOS 時，請勿關閉或重置系統！若是這麼做，將可能導致系統
開機失敗。
• 對於 BIOS Updater 1.04 或更高版本，當 BIOS 升級完畢後，工具程序
會自動回到 DOS 畫面。
• BIOS 程序的出廠默認值可讓系統運行處於最佳性能。若系統因您改變
BIOS 程序而導致不穩定，請讀取出廠默認值來保持系統的穩定。請
在 Exit 菜單中選擇【Load Optimized Defaults】項目。詳細說明請參
考“2.9 退出 BIOS 程序”一節。
• 若您之前移除了所有 SATA 硬盤，當 BIOS 升級完成後，請確認將所有
SATA 硬盤重新連接到主板。
ASUSTek BIOS Updater for DOS V1.18
Current ROM
Update ROM
A:
Note
[Enter] Select or Load [Tab] Switch [V] Drive Info
[Up/Down/Home/End] Move [B] Backup [Esc] Exit
P8H61LX3.ROM 4194304 2011-01-11 17:30:48
PATH: A:\
BOARD: P8H61-M LX3
VER: 0301
DATE: 11/28/2011
BOARD: Unknown
VER: Unknown
DATE: Unknown
