Chapter 2: Hardware Information
2-10
5. PlacetheSATA/SASstoragedevice
into the tray then secure it with four
screws.
6. Insert the drive tray and storage device
assembly all the way into the depth of
the bay until just a small fraction of the
tray edge protrudes.
7. Push the tray lever until it clicks and
secures the drive tray in place.
The drive tray is correctly placed
when its front edge aligns with the
bay edge.
8. Repeatsteps1to7toinstalltheother
SATA/SASstoragedevices.
Wheninstalled,theSATA/SASconnectoronthedriveconnectstotheSATA/SASinterface
on the backplane.
