Chapter 2: Hardware Information
2-10
2 CPU Configuration (symmetric population)
Modes DIMM_F2 DIMM_F1 DIMM_E2 DIMM_E1 DIMM_D2 DIMM_D1
AD
DCPMM DRAM1 DCPMM DRAM1 DCPMM DRAM1
MM
DCPMM DRAM1 DCPMM DRAM1 DCPMM DRAM1
AD+MM
DCPMM DRAM3 DCPMM DRAM3 DCPMM DRAM3
AD
DRAM1 DRAM1 DCPMM DRAM1
MM
DRAM2 DRAM2 DCPMM DRAM2
AD+MM
DRAM3 DRAM3 DCPMM DRAM3
AD
DRAM1 DCPMM DRAM1 DCPMM DRAM1
MM
DRAM1 DCPMM DRAM1 DCPMM DRAM1
AD+MM
DRAM3 DCPMM DRAM3 DCPMM DRAM3
AD
DCPMM DRAM1 DRAM1
MM
DCPMM DRAM1 DRAM1
AD+MM
DCPMM DRAM3 DRAM3
AD
DCPMM DRAM1 DRAM1 DRAM1 DRAM1
2 CPU Configuration (symmetric population)
Modes DIMM_C2 DIMM_C1 DIMM_B2 DIMM_B1 DIMM_A2 DIMM_A1
AD
DCPMM DRAM1 DCPMM DRAM1 DCPMM DRAM1
MM
DCPMM DRAM1 DCPMM DRAM1 DCPMM DRAM1
AD+MM
DCPMM DRAM3 DCPMM DRAM3 DCPMM DRAM3
AD
DRAM1 DRAM1 DCPMM DRAM1
MM
DRAM2 DRAM2 DCPMM DRAM2
AD+MM
DRAM3 DRAM3 DCPMM DRAM3
AD
DRAM1 DCPMM DRAM1 DCPMM DRAM1
MM
DRAM1 DCPMM DRAM1 DCPMM DRAM1
AD+MM
DRAM3 DCPMM DRAM3 DCPMM DRAM3
AD
DCPMM DRAM1 DRAM1
MM
DCPMM DRAM1 DRAM1
AD+MM
DCPMM DRAM3 DRAM3
AD
DCPMM DRAM1 DRAM1 DRAM1 DRAM1
(continued on the next page)
