2-11
ASUS RS720-E9 Series
2 CPU Configuration (symmetric population)
Modes DIMM_M2 DIMM_M1 DIMM_L2 DIMM_L1 DIMM_K2 DIMM_K1
AD
DCPMM DRAM1 DCPMM DRAM1 DCPMM DRAM1
MM
DCPMM DRAM1 DCPMM DRAM1 DCPMM DRAM1
AD+MM
DCPMM DRAM3 DCPMM DRAM3 DCPMM DRAM3
AD
DRAM1 DRAM1 DCPMM DRAM1
MM
DRAM2 DRAM2 DCPMM DRAM2
AD+MM
DRAM3 DRAM3 DCPMM DRAM3
AD
DRAM1 DCPMM DRAM1 DCPMM DRAM1
MM
DRAM1 DCPMM DRAM1 DCPMM DRAM1
AD+MM
DRAM3 DCPMM DRAM3 DCPMM DRAM3
AD
DCPMM DRAM1 DRAM1
MM
DCPMM DRAM1 DRAM1
AD+MM
DCPMM DRAM3 DRAM3
AD
DCPMM DRAM1 DRAM1 DRAM1 DRAM1
2 CPU Configuration (symmetric population)
Modes DIMM_J2 DIMM_J1 DIMM_H2 DIMM_H1 DIMM_G2 DIMM_G1
AD
DCPMM DRAM1 DCPMM DRAM1 DCPMM DRAM1
MM
DCPMM DRAM1 DCPMM DRAM1 DCPMM DRAM1
AD+MM
DCPMM DRAM3 DCPMM DRAM3 DCPMM DRAM3
AD
DRAM1 DRAM1 DCPMM DRAM1
MM
DRAM2 DRAM2 DCPMM DRAM2
AD+MM
DRAM3 DRAM3 DCPMM DRAM3
AD
DRAM1 DCPMM DRAM1 DCPMM DRAM1
MM
DRAM1 DCPMM DRAM1 DCPMM DRAM1
AD+MM
DRAM3 DCPMM DRAM3 DCPMM DRAM3
AD
DCPMM DRAM1 DRAM1
MM
DCPMM DRAM1 DRAM1
AD+MM
DCPMM DRAM3 DRAM3
AD
DCPMM DRAM1 DRAM1 DRAM1 DRAM1
AD - APP DIRECT MODE
MM - MEMORY MODE
AD+MM - MIXED MODE
DRAM1 - RDIMM, RDIMM 3DS, LRDIMM, LRDIMM 3DS
DRAM2 - RDIMM only
DRAM3 - RDIMM, RDIMM 3DS, LRDIMM
DCPMM - DC PERSISTENT MEMORY
