5-46 Chapter 5: BIOS setup
5.10 Tool menu
The Tool menu items allow you to congure options for special functions. Select an
item then press <Enter> to display the submenu.
Be used to update BIOS
ASUS EZ Flash 2 Utility
ASUS EZ Flash 2 Utility
Allows you to run ASUS EZ Flash BIOS ROM Utility when you press <Enter>.
Check section 5.1.2 ASUS EZ Flash 2 Utility for details.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Server Mgmt Event Logs Boot Monitor Security Tool Exit
To clear the user password, follow the same steps as in changing a user password,
but press <Enter> when prompted to create/conrm the password. After you clear
the password, the
User Password
item on top of the screen shows
Not Installed
.
5.11 Exit menu
The Exit menu items allow you to save or discard your changes to the BIOS items.
Exit system setup without
saving any changes.
Version 2.15.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Server Mgmt Event Logs Boot Monitor Security Tool Exit
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Discard Changes & Exit
Save Changes & Reset
Discard Changes & Reset
Restore Defaults
Boot Override
SATA P2: ASUS DRW-2014L1T
AMI Virtual CDROM 1.00
SATA P3: WDC WD800JD-00LSA0
AMI Virtual Floppy0 1.00
IBA GE Slot 0700 v1376
IBA GE Slot 0701 v1376
IBA GE Slot 0702 v1376
IBA GE Slot 0703 v1376
Launch EFI Shell from lesystem device
Pressing <Esc> does not immediately exit this menu. Select one of the options
from this menu or <F10> from the legend bar to exit.
