Chapter 1: Product introduction1-4
1.3 Systemspecications
The ASUS RS920-E7/RS8 and RS926-E7/RS8 are servers featuring the ASUS
Z9PX-Q32 Series server board.The server supports the
Intel
®
Xeon
®
E5-4600 processor family, plus other latest technologies through the
chipsets onboard.
(continued on the next page)
Model Name RS926-E7/RS8 RS920-E7/RS8
Processor Support
4 x LGA 2011 socket
Intel
®
Xeon
®
Processor E5-4600 Product Family (up
to 130W)
Intel
®
QuickPath Interconnect (QPI) 6.4/7.2/8.0 GT/s
Core Logic
Intel
®
C602-A chipset
Memory Total Slots
32 (4-channel per CPU, 2 DIMM per channel)
Capacity
Maximum up to 1024GB (RDIMM)
Maximum up to 256GB (UDIMM)
Memory Type
DDR3 800/1066/1333/1600 RDIMM
DDR3 1066/1333 ECC UDIMM/Non-ECC UDIMM
DDR3 1066/1333 LR-DIMM
Memory Size
1GB, 2GB, 4GB, 8GB, 16GB, 32GB* (RDIMM)
1GB, 2GB, 4GB, 8GB* (UDIMM)
8GB, 16GB, 32GB* (LRDIMM)
Expansion
Slots
Total PCI/
PCI-X/PCI-E
Slots
6 (PCI riser card required)
Slot type
Full-length
4 x PCI-E x16
(2 x Gen3 x16 Link or 4 x Gen3 x8 Link)
Half-length/Low-prole
2 x PCI-E x8 (Gen3 x8 Link)
Additional
Slot
PIKE slot (PCI-E Gen3 x8 Link)
Storage SATA
Controller
Intel
®
C602-A Chipset
- 2 x SATA 6 Gb/s(black), 4 x SATA 3 Gb/s(black)
AHCI port
- 4 x SATA 3 Gb/s (blue) SCU ports
Intel
®
Rapid Storage Technology (for Windows only)
Supports RAID 0, RAID 1, RAID 10, and RAID 5
LSI
®
Mega RAID (for Windows/Linux)
Supports software RAID 0, 1, & 10
SAS
Controller
Optional:
ASUS PIKE 2008 8-port SAS2 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS2 6G RAID card
ASUS PIKE 2108 8-port SAS2 6G H/W RAID card
HDD Bays
8 x Hot-swappable 3.5” HDD Bays
