Asus RS920-E7/RS8 User Manual

Chapter 2: Hardware setup2-10
Memory population table
For UDIMM, RDIMM and LRDIMM (Single Rank, Dual Ranks, Quad rank)
CPU1 Conguration
A2 A1 B2 B1 C2 C1 D2 D1
1 DIMMs
P
2 DIMMs
P P
4 DIMMs
P P P P
8 DIMMs
P P P P P P P P
CPU1 + CPU2 Conguration
A2 A1 B2 B1 C2 C1 D2 D1 E2 E1 F2 F1 G2 G1 H2 H1
2 DIMMs
P P
4 DIMMs
P P P P
6 DIMMs
P P P P P P
8 DIMMs
P P P P P P P P
10 DIMMs
P P P P P P P P P P
12 DIMMs
P P P P P P P P P P P P
14 DIMMs
P P P P P P P P P P P P P P
16 DIMMs
P P P P P P P P P P P P P P P P
CPU1 + CPU2 + CPU3 + CPU4 Conguration
A2 A1 B2 B1 C2 C1 D2 D1 E2 E1 F2 F1 G2 G1 H2 H1
4 DIMMs
P P
8 DIMMs
P P P P
12 DIMMs
P P P P P P
16 DIMMs
P P P P P P P P
20 DIMMs
P P P P P P P P P P
24 DIMMs
P P P P P P P P P P P P
28 DIMMs
P P P P P P P P P P P P P P
32 DIMMs
P P P P P P P P P P P P P P P P
CPU1 + CPU2 + CPU3 + CPU4 Conguration
I2 I1 J2 J1 K2 K1 L2 L1 M2 M1 N2 N1 O2 O1 P2 P1
4 DIMMs
P P
8 DIMMs
P P P P
12 DIMMs
P P P P P P
16 DIMMs
P P P P P P P P
20 DIMMs
P P P P P P P P P P
24 DIMMs
P P P P P P P P P P P P
28 DIMMs
P P P P P P P P P P P P P P
32 DIMMs
P P P P P P P P P P P P P P P P
2.3.2 MemoryCongurations
You may install 1GB/2GB/4GB/8GB/16GB/32GB Registerd or 1GB/2GB/4GB/8GB
Unbuffered with ECC/Non-ECC DDR3 DIMMs into the DIMM sockets using the
memory congurations in this section.

Asus RS920-E7/RS8 Specifications

General

Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-4600
Motherboard chipset	Intel® C602
Compatible processor series	Intel® Xeon®
Number of processors supported	4
Maximum RDIMM memory	1024 GB
Maximum UDIMM memory	256 GB
Number of DIMM slots	32
Supported memory types	DDR3-SDRAM
Supported RDIMM clock speeds	800, 1066, 1333, 1600 MHz
Supported UDIMM clock speeds	1066, 1333 MHz
Supported DIMM module capacities	16GB, 1GB, 2GB, 4GB, 8GB
RAID levels	0, 1, 5, 10
Hot-swap HDD bays	Yes
Storage drive sizes supported	3.5 \
Number of storage drives supported	8
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA II, Serial ATA III
Graphics card	AST2300
Graphics card family	Aspeed
Maximum graphics card memory	16 MB
LAN controller	Intel® I350-AM4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Chassis type	Rack (2U)
PS/2 ports quantity	1
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	5
PCI Express x8 slots	2
Compatible operating systems	CentOS 5.6 32/64-bit, Windows Server 2008 R2, Windows Server 2008 R2 Enterprise, Windows Server 2008 Enterprise 32/64-bit, RedHat Enterprise Linux AS5.6/6.0 32/64-bit, SuSE Linux Enterprise Server 11.2 32/64-bit, VMWare ESX4.1/ESXi4.1
Safety	CE, EN55022
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Power supply	1620 W

Weight and Dimensions

Depth	750 mm
Width	444 mm
Height	88 mm
Weight	20000 g
