Asus RS920-E7/RS8 User Manual

5-20 Chapter 5: BIOS setup
Allows you to enable or
disable BIOS ACPI Auto
Conguration.
Intel(R) VT-d [Disabled]
Intel(R) VT-d [Disabled]
Allows you to enable or disable Intel
®
VT-d.
Conguration options: [Enabled] [Disabled]
Intel(R)VTforDirectedI/OConguration
The following item appears only when you set
Intel(R) VT-d
to [Enabled].
Coherency Support [Disabled]
Allows you to enable/disable VT-d Engine Coherency support.
Conguration options: [Disabled] [Enabled]
ATS Support [Disabled]
Allows you to enable/disable VT-d Engine address translation services (ATS)
support. Conguration options: [Disabled] [Enabled]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
5.4.4 PCHSATAConguration
(1)IDE Mode. (2)AHCI Mode.
(3)RAID Mode.
SATA Port1 Not Present
SATA Port2 ASUS DWR ATAPI
SATA Port3 WDC WD800JD(80.0GB)
SATA Port4 Not Present
SATA Port5 Not Present
SATA Port6 Not Present
SATA Mode [AHCI Mode]
S.M.A.R.T. Status Check [Enabled]
Port 1 Staggered Spin-up [Disabled]
Port 2 Staggered Spin-up [Disabled]
Port 3 Staggered Spin-up [Disabled]
Port 4 Staggered Spin-up [Disabled]
Port 5 Staggered Spin-up [Disabled]
Port 6 Staggered Spin-up [Disabled]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.15.1219. Copyright (C) 2011 American Megatrends, Inc.

Asus RS920-E7/RS8 Specifications

General

Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-4600
Motherboard chipset	Intel® C602
Compatible processor series	Intel® Xeon®
Number of processors supported	4
Maximum RDIMM memory	1024 GB
Maximum UDIMM memory	256 GB
Number of DIMM slots	32
Supported memory types	DDR3-SDRAM
Supported RDIMM clock speeds	800, 1066, 1333, 1600 MHz
Supported UDIMM clock speeds	1066, 1333 MHz
Supported DIMM module capacities	16GB, 1GB, 2GB, 4GB, 8GB
RAID levels	0, 1, 5, 10
Hot-swap HDD bays	Yes
Storage drive sizes supported	3.5 \
Number of storage drives supported	8
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA II, Serial ATA III
Graphics card	AST2300
Graphics card family	Aspeed
Maximum graphics card memory	16 MB
LAN controller	Intel® I350-AM4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Chassis type	Rack (2U)
PS/2 ports quantity	1
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	5
PCI Express x8 slots	2
Compatible operating systems	CentOS 5.6 32/64-bit, Windows Server 2008 R2, Windows Server 2008 R2 Enterprise, Windows Server 2008 Enterprise 32/64-bit, RedHat Enterprise Linux AS5.6/6.0 32/64-bit, SuSE Linux Enterprise Server 11.2 32/64-bit, VMWare ESX4.1/ESXi4.1
Safety	CE, EN55022
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Power supply	1620 W

Weight and Dimensions

Depth	750 mm
Width	444 mm
Height	88 mm
Weight	20000 g
