ASUS RS920-E7/RS8; RS926-E7/RS8 5-43
5.8 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you
to change the fan settings.
CPU1 Temperature 54.0ºC/129.2ºF
CPU2 Temperature N/A
CPU3 Temperature N/A
CPU4 Temperature N/A
CPU FAN1 Speed 5378 RPM
CPU FAN2 Speed N/A
FRNT FAN1 Speed N/A
FRNT FAN2 Speed N/A
FRNT FAN3 Speed N/A
FRNT FAN4 Speed N/A
FRNT FAN5 Speed N/A
+VTT_CPU +1.026 V
VCORE1 +0.996 V
VCORE2 +0.996 V
VCORE3 +0.852 V
VCORE4 +0.866 V
+VDDQ_CPU1 +1.556 V
+VDDQ_CPU2 N/A
+VDDQ_CPU3 N/A
+VDDQ_CPU4 N/A
+5VSB +4.460 V
+5V +4.996 V
+12V +11.592 V
+3.3V +3.276 V
+3.3VSB +3.234 V
Scroll down to display the following items:
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Server Mgmt Event Logs Boot Monitor Security Tool Exit
Version 2.15.1219. Copyright (C) 2011 American Megatrends, Inc.
VBAT +3.168 V
FAN Speed Control [Generic Node]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Version 2.15.1219. Copyright (C) 2011 American Megatrends, Inc.
CPU 1 / 2 / 3 / 4 Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU and
motherboard component temperatures.
CPU FAN1/2 Speed; FRNT FAN1–5 Speed [xxxx RPM] or [N/A]
The onboard hardware monitor automatically detects and displays the speed of
CPU fans, front fans in rotations per minute (RPM). If the fan is not connected to
the motherboard, the eld shows N/A.
