Asus RS920-E7/RS8 User Manual

ASUS RS920-E7/RS8; RS926-E7/RS8 4-3
Internal connectors Page
1. Serial ATA 6.0/3.0 Gb/s connectors (7-pin SATA6G_1-2 [black])
(7-pin SATA3G_3-6 [black])
4-8
2. ISAS connectors
4-9
3. PSAS connectors
4-9
4. USB connectors (10-1 pin USB56, A-Type USB10)
4-10
5. Hard disk activity LED connector (4-pin HDLED1)
4-10
6. CPU and front fan connectors (4-pin CPU_FAN1-2,
FRNT_FAN1–5)
4-11
7. Serial General Purpose Input/Output connectors
(6-1 pin SGPIO1, 8-1 pin PSGPIO 1/2 and ISGPIO1)
4-12
8. Serial port connector (10-1 pin COM1)
4-13
9. TPM connector (20-1 pin TPM1)
4-13
10. Power Supply SMBus connector (6-1 pin PSUSMB1)
4-14
11. EATX power connectors (24-pin ATXPWR1, 8-pin ATX12V1)
4-15
12. System panel connector (20-1 pin PANEL1)
4-16
13. Auxiliary panel connector (20-2pin AUX_PANEL1)
4-17
Internal LEDs Page
1. Standby Power LED (SB_PWR1) 4-18
2. DIMM Error LED (ERR_DIMM)
4-18
3. CPU warning LED (ERR_CPU1/2/3/4)
4-19
4. CATT Error LED (CATTERR_LED1)
4-19
5.
Baseboard Management Controller LED (BMC_LED1) 4-20
6. Q-Code LED (LED1_LED2)
4-20

Asus RS920-E7/RS8 Specifications

General

Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-4600
Motherboard chipset	Intel® C602
Compatible processor series	Intel® Xeon®
Number of processors supported	4
Maximum RDIMM memory	1024 GB
Maximum UDIMM memory	256 GB
Number of DIMM slots	32
Supported memory types	DDR3-SDRAM
Supported RDIMM clock speeds	800, 1066, 1333, 1600 MHz
Supported UDIMM clock speeds	1066, 1333 MHz
Supported DIMM module capacities	16GB, 1GB, 2GB, 4GB, 8GB
RAID levels	0, 1, 5, 10
Hot-swap HDD bays	Yes
Storage drive sizes supported	3.5 \
Number of storage drives supported	8
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA II, Serial ATA III
Graphics card	AST2300
Graphics card family	Aspeed
Maximum graphics card memory	16 MB
LAN controller	Intel® I350-AM4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Chassis type	Rack (2U)
PS/2 ports quantity	1
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	5
PCI Express x8 slots	2
Compatible operating systems	CentOS 5.6 32/64-bit, Windows Server 2008 R2, Windows Server 2008 R2 Enterprise, Windows Server 2008 Enterprise 32/64-bit, RedHat Enterprise Linux AS5.6/6.0 32/64-bit, SuSE Linux Enterprise Server 11.2 32/64-bit, VMWare ESX4.1/ESXi4.1
Safety	CE, EN55022
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Power supply	1620 W

Weight and Dimensions

Depth	750 mm
Width	444 mm
Height	88 mm
Weight	20000 g
