EN 33
TECHNICAL SPECIFICATIONS
Technical data
Hob
Unit Value
Pruduct type Built-in
Dimensions Width mm 830
Depth mm 520
Height mm 230
Power supply voltage/frequency V / Hz 220-240 / 50
Power W 7620
Weight Kg 21
Extraction unit
Airflow max* - Exhaust installation m
3
/h 550
Noise max* - Recirculating installation dBA 66
Extraction unit power W 220
* Maximum speed (boost excluded)
Information according regulation (EU) 66/2014
Measurements according EN60350-2
Model identification
HIDD8471EV
HIDD8472EV
Type of hob Induction hob
Number of electric cooking zones and/or areas 4
Heating technology Induction cooking
zones and cooking
areas
For non-circular cooking zones or areas: lenght and width of useful
surface area per electric heated cooking zone or area
21.0 x 19.0 cm
Energy consumption per cooking zone or area calculated per kg (EC
electric
hob
) in Wh/kg
170
Energy consumption for the hob calculated per kg (EC
electric hob
) in Wh/kg 170
