Table/Desk Installation
1 Attach the wedge.
Insert the bottom tabs into the slots as shown. Push gently on
the tabs at the large end of the base while locking them into
place against the base.
2 Connect the line cord(s) to the telephone and your
modular jack(s).
• If you have a single two-line wall jack, use only the black
(4-connector) line cord. Plug one end into the jack labeled L1
OR L1/L2 on the back of the telephone. Plug the other end
into the wall jack. Make sure the cord snaps firmly into place
at both ends.
continued on page 6
5
INSTALLATION
INSTALLATION
Black telephone
line cord
Two-line modular
wall jack
To Next Page
