KEYS
Cycle keys
The cycle keys are used to start and to stop a measurement cycle.
Key Name Function
Start On the Program screen, starts a measurement cycle and opens the
Measurement cycle screen.
Reset
Stops the measurement cycle in progress and returns to the
Program screen.
Navigation keys
The navigation keys are used to select menus/options and change parameter values.
Key Name Function
Up key
Scrolls up or increases numerical values.
Down key
Scrolls down or decreases numerical values.
OK Returns to the MAIN MENU screen or opens menus and options,
validates parameters.
Esc Returns to previous screen (until the Program screen), escapes
without modifying parameters.
Smart key
Smart key is a programmable key that provides direct access to a function selected by
the user.
Key Name Function
Smart key
Starts a measurement cycle (default, programmable).
This key is programmable through the MAIN MENU screen:
MAIN MENU > CONFIGURATION > MISCELLANEOUS > SMART KEY
