ATEQ F28+ User Manual

QSG_F28+.394.00_EN_01 / 2019-02-25
41 / 42
Specifications
CHARACTERISTICS
Technical characteristics of the device.
Main characteristics
Characteristics Values
Dimensions: height x width x depth 157 x 299 x 136 mm (6.18 x 11.77 x 5.35")
Weight About 3.5 kg (7.70 lb)
Electrical power supply 24 V DC - 2A
Overvoltage category II
Pressure range Several ranges from vacuum to 2 MPa (290 PSI)
Leak measurement range 3 FS: 50 / 500 / 5000 Pa
Protection Device protection level IP2
Operation temperature +5 °C to + 45 °C (+ 41 °F to 113 °F)
Storage temperature 0 °C to +60 °C (32 °F to 140 °F)
Operation altitude Up to 2000 m (6500')
Relative humidity 80 % at 31 °C (87 °F) and 50 % at 40 °C (104 °F)
