ATEQ F28+ User Manual

QSG_F28+.394.00_EN_01 / 2019-02-25
9 / 42
Your ATEQ F28+
FRONT PANEL
Ref Name Description
1
J7 24 V DV power supply
2
- Power on indicator
3
J9 Program selection extension connector
4
- Not used
5
- 0.6MPa (87PSI) air valve supply
6
- Regulated air pressure input 1 (option)
7
- Regulated air pressure input 2 (option)
8
J5 Fieldbus connector (option)
9
J6 Fieldbus connector (option)
10
ATEQ Part number / Serial number
11
J2 USB connector to PC
12
J3 USB connector to remote control
13
J10 Outputs code board connector (digital inputs/outputs)
14
J8 Relay board connector (digital inputs/outputs)
15
- Ground
16
JX Profibus (option)
17
J12 RS232 connector
