Quick start manual - F5200
MR-F5200B-U Quick start manual ATEQ F5200 Page 11/17
5. PARAMETERS
Main parameters to configure: see the manuals CDROM for further information.
Fill time:
Time to fill the part to the test pressure.
Stabilization time:
Time to equalize the pressure between the TEST and
REFERENCE components.
Test time:
Leak measurement time, it depends of the reject level value
and the work mode programmed.
Dump time:
Time to back the part to the atmospheric pressure. Dump
time by default is zero.
Pressure unit:
Pressure unit (bar, mbar, PSI, Pa, kPa, MPa).
Maximum fill:
Maximum level of the fill pressure.
Minimum fill:
Minimum level of the fill pressure.
Fill instruction:
Test pressure that the device will automatically regulate.
Remind: the input pressure must be at least greater than
100 kPa (1 bar) of the test pressure.
Reject unit :
Leak unit displayed. If a flow unit is selected, two
parameters are added.
Test reject:
Level for the test part is fail.
Reference reject:
Level for the reference part is fail (possible problem on
this part).
Note: when the reference reject value is 0, the device takes
into account the absolute value of the symmetrical test
reject.
Functions :
Extended parameters access menu, that must be
activated in the CONFIGURATION then EXTENDED
MENUS menu.
Note: if no extended parameter has been activated from
these menus, the FUNCTION menu is empty.
Edition, duplication, deletion or copy of a test program, program number to start:
see the manuals CDROM for further information.
