MR-F5200B-U Quick start manual ATEQ F5200 Page 15/17
ACCESSORIES AND CHARACTERISTICS
See the manuals CDROM for further information.
1. ACCESSORIES FITTED WITH THE DEVICE
Power supply:
The power supply cable of the F5200
allows its connection to the mains supply
network (from 100 to 240V AC).
2. ACCESSORIES IN OPTION
Master leaks: the master leaks are used to check the device calibration.
Micrometer valve and Leak Calibrator (CDF).
Automatic connectors with expandable seals
Filtration kit.
Singles remote controls.
3. TECHNICAL CHARACTERISTIC OF THE F5200
Case dimensions H x L x D (mm): 140 x 250 x 250
Overall dimensions (mm): 140 x 250 x 320
Electric power supply:
100 à 240 V AC / 2 A
Pneumatics connections:
3/5, 4/6 or 6/8
Weight (kg): about 6
Format :
½ 19 inches
Running temperature:
+10°C to +45°C
Storage temperature:
0°C to +60 °C
