Parameter
Descriptions
The Digital Filtering setting [ FILt ] on the Series 16 process controller allows the operator to
compensate for noise which may cause the last digits of the PV display to become unstable.
Sampling rate is not affected. The settings are time constants, in seconds, with 0.1 equivalent to
“no filtering.”
Display Parameter Available Selections
SnSr
Sensor Type
cA - Type K thermocouple
J - Type J thermocouple
n - Type N thermocouple
r - Type R thermocouple
t - Type T thermocouple
S - Type S thermocouple
PL11 - Type Platinel II thermocouple
P - 100 ohm platinum RTD
d - RTD with digital range
OUt1
Output 1 Action
HT.P - Heat PID
Ht.O
ALr - Alarm
OUt2
Output 2 Action
CL.P - Cool PID
CL.O
ALr - Alarm
SN.00
Input Zero Level
U.Su - unsuppressed 0 to 20 mA
Su - suppressed 4 to 20mA
Dec.P
Decimal Point
999, 9 9. 9. ,orr 9.99
FILt
Digital Filtering
0. 1 , 1, 10
Out1
Output 1 Action
Pid - PID
On.F
Alr - Alarm
Out2
Output 2 Action
Pid - PID
On.F
Alr - Alarm
Col.t
Water Cooling Type
H2o - non-linear output
Normal Cooling
nor - linear output
A1.H1
Alarm 1 Select / Enable
Lo / Hi
A1.Pd
Alarm 1 type
Pr / dE - select process or deviation alarms
A1.OP
Alarm 1 output
OFF / nor / LAt
A2.H1
Alarm 2 Select / Enable
Lo / Hi
A2.Pd
Alarm 2 type
Pr / dE - select process or deviation alarms
A2.OP
Alarm 2 output
OFF / nor / LAt
Unit
Measurement Units
F / C - select
o
F or
o
C
MENU "05"
How Do I Get Here?
