Parameter
Descriptions
With the Heater Break Alarm option, [ Id.no ] changes to Heater Current Reading [ Ht.rd ]
(indication only) and [ bAUd ] changes to Heater Break Alarm Setpoint [ Ht.SP ] (indication only,
either 00-30 A or 00-60 A).
Display Parameter Available Selections
Id.no
Device ID number
(remote communications)
00 to 99
bAUd
Comm details
3. 0. 7 - 300 baud, odd parity, 7 data bits, 2 stop bits
6. 0. 7 - 600 baud, odd parity, 7 data bits, 2 stop bits
12.0.7 - 1200 baud, odd parity, 7 data bits, 2 stop bits
24.0.7 - 2400 baud, odd parity, 7 data bits, 2 stop bits
3.n.8 - 300 baud, none parity, 8 data bits, 1 stop bit
6.n.8 - 600 baud, none parity, 8 data bits, 1 stop bits
12.n.8 - 1200 baud, none parity, 8 data bits, 1 stop bits
CAL.L
Calibration Low Preset at factory
CAL.H
Calibration High Preset at factory
MENU "04"
