Athena 16 Series User Manual

Digital
Communications
Communications Parameter List (Temperature Controller)
Parameter No. Description Display Minimum Maximum
00 Process Value
nnnn
Sensor dependent
01 Setpoint
nnnn
Low Limit High Limit
02 Access Code
Ac.Cd
00 05
03 Gain Output 1
Gn.o1
00 400
04 Gain Ratio 2
Gr.02
0.0 2.0
05 Rate
rAtE
00 900
06 Reset
rSEt
00 3600
07 Heat Hysteresis
H.HYS
01 100
08 Cool Hysteresis
C.HYS
01 100
09 Cool Spread
c.SPr
00 100
10 Damping
dPnG
00
Low/Normal/High
11 Alarm 1
ALr1
Range dependent
12 Alarm 2
ALr2
Range dependent
13 Cycle Time 1
CY.t1
00 120
14 Cycle Time 2
CY.t2
00 120
15 Setpoint Target Time
Sp.tt
󰀨 100
16 Low Setpoint Limit
L.SP.L
Sensor dependent
17 High Setpoint Limit
U.SP.L
Sensor dependent
18 Controller ID
Id.no
00 99
19 Baud Rate
bAUd
300 2400
Communications Parameter List (Process Controller)
Parameter No. Description Display Minimum Maximum
00 Process Value
nnnn
Low Scale High Scale
01 Setpoint
nnnn
Low Scale High Scale
02 Access Code
Ac.Cd
00 05
03 Gain Output 1
Gn.o1
00 400
04 Gain Ratio 2
Gr.02
0.0 2.0
05 Rate
rAtE
00 900
06 Reset
rSEt
00 3600
07 Hysteresis 1
HYS.1
01 100
08 Hysteresis 2
HYS.2
01 100
09 Spread 2
SPr.2
00 100
10 Damping
dPnG
00
Low/Normal/High
11 Alarm 1
ALr1
Low Scale High Scale
12 Alarm 2
ALr2
Low Scale High Scale
13 Cycle Time 1
CY.t1
00 120
14 Cycle Time 2
CY.t2
00 120
15 Setpoint Target Time
Sp.tt
󰀨 100
16 Low Scale
L.SCL
-1999 9999
17 High Scale
H.SCL
-1999 9999
18 Controller ID
Id.no
00 99
19 Baud Rate
bAUd
300 2400
