24 1800296 C
Filling the Liquid Aerosol Reagent Reservoir
1. Check the liquid aerosol reagent level at the Liquid Level
Indicator located at the back of the unit. If liquid aerosol
reagent is not visible in the Liquid Level Indicator, fill the
generator as necessary.
2. To fill the generator, remove the generator fill cap at the top of
the generator and fill with liquid aerosol reagent while noting
the level in the sight tube.
3. Fill unit until liquid aerosol reagent reaches the top of the
Liquid Level Indicator. DO NOT over fill.
4. Replace the fill cap and hand tighten. DO NOT operate the
equipment without the fill cap in place.
Warning – Fire Hazard
Take caution against liquid aerosol reagent spillage. Always
use a funnel. In case of spillage clean up immediately.
Input Inert Gas
Connect standard pressure rated ¼ inch (6.3 mm) outside diameter
tubing (user supplied) from the INERT GAS source regulator to the
tube fitting at the inert gas inlet.
Warning – Fire Hazard
DO NOT USE OXIDIZING OR FLAMMABLE GASES
SUCH AS COMPRESSED AIR. NEVER operate the unit
with anything except INERT GAS such as nitrogen, carbon
dioxide, or argon. Make sure all the compressed gas
connections are secure.
Note
The generator will not produce aerosol unless there is sufficient
pressure and flow of compressed gas.
Warning – Fire Hazard
The 5C Thermal Aerosol Generator is factory pre-set for
liquid aerosol reagents specified by the part number. DO
NOT USE different liquid aerosol reagents other what is
specified. Contact ATI Customer/Technical Service for
questions regarding use of other liquid aerosol reagents.
